Export data
You can export data from Dipla in different formats. To do this, follow these steps:
Data is always exported based on one or more project sections. Make sure you have drawn a project section around the elements you want to export. The elements must be entirely within this project section.
Open the Management module and open the project you want to export from
Filter one or more project sections
If desired, refine the selection using the regular filter
Click the printer button on the right
Click Export data
Extra parameter
If you want to export data from the execution plan, you can specify which standards (task names) the export should contain, as well as the start and end dates between which the tasks must fall.
Then click Next
Dashboard
You will now see several tables with links for exporting either a shapefile or KML.
The first table groups all selected project sections
The following tables show the elements/tasks per project section
